Technical Data
- Length: 1,000 mm
- Width (inside / outside): 100 mm/228 mm
- Height (inside / outside): 155 mm/248 mm
- Weight: 8.7 kg
- Material: PP Copolymer
(glass-fiber reinforced, UV-stable, flame-retardant) - Fire protection classification: DIN EN 13501-1: K1 according to DIN 53438 part 2; DIN EN ISO 11925-2; DIN EN 13501-1
- Fire resistance: DIN EN 60695-2-11 / test temperature: 550 °C
- Temperature resistance: DIN EN ISO 75-2 (method B): -20 °C to +150 °C
- Load bearing capacity: Class A15 (9 kN) according to DIN EN 124–1/ DIN EN 1433
- Electrical properties: DIN EN 60243-1 / VDE 0303-21/ dielectric strength: > 40 kV
- Impact resistance: IK11 (50 joules), the highest classification according to DIN EN 62262
- Slip resistance: Lid surface Class R11 in accordance with DIN EN 16165
